Green DWM Copeland Semi-Hermetic Compressor Discus Series with 45hp for R22 R404A

Name: Green DWM Copeland SemiHermetic Compressor Discus Series with 45hp for R22 R404A
Brand: DWM COPELAND
Price: 1 USD

China Green DWM Copeland Semi-Hermetic Compressor Discus Series with 45hp for R22 R404A wholesale

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5,00 pcs per month

Delivery Time : 7-10 working days after receiving payment

Packaging Details : Wooden case

Brand Name : DWM COPELAND

Model Number : DK DL

Certification : UL CCC CE ROSH

Place of Origin : Garmany

MOQ : 1PCS

Price : discussed

Piston Type : Semi-hermetic

Configuration : Stationary

Drive Mode : Electric

Standard : R134a

color : green

GAS : R134a R404A/R507

In stock : Yes

Original : Garmany

Contact Now

45hp R22 R404A DWM Copeland Semi Hermetic Compressor Discus Series 4

1.The new semi-hermetic refrigeration compressor product line described here combines the latest compressor designs with the newest refrigerants for high performance,long service life,and broad

application flexibility. Included are air-cooled models up to 5HP,refrigerant-cooled Discus, S models

up to 70HP, and internally compounded two-stage models. Models supplied with ester oil are universally

capable of operating with R404A,R507,R407C,R134A or R22, thus reducing stock for a broad range

of applications.

2.The use of compressors for HFCs,R404A,R507,R407C,R134A or R22 leads to a number of specific

issues regarding their application and operational behaviour. There are briefly reviewed in the following pages. Further information on these refrigerants is available from suppliers.

3.Because of the different vapour-pressure characteristics of R404A compared with R502 and R134a

Compared with R12, particular attention must be paid to the vapour pressures resulting from the ambient temperature(especially at standstill). The limits permitted for the compressor and other system components must not be exceeded.

Green DWM Copeland Semi-Hermetic Compressor Discus Series with 45hp for R22 R404A

COMPRESSOR	Power (H.P.)							COOL I NG CAPACITY at20℃ Suction Gas Temperature watts (50Hz)
		Displacement (m³/hr @1450rpm)
			Suction Line (inch)
MODELS				Suction Line (inch)
					No.of cylinders
						Cond Temp
											Evapoating Temperayure

								+12.5℃	+7℃	0℃	-5℃	-10℃	-15℃	-20℃	-25℃	-30℃	-35℃	-40℃	-50℃


R404A/R507 LOW/MED/HIGH TEMPERATURE

D2DD*-50X	5	19.3	1-3/8"	7/8"	2	30℃			22440	18650	15310	12410	9900	7740	5900	4340	3030	1950
						50℃			15220	12490	10110	8040	6260	4710	3380	2230	1220
D2DB*-50X	5	28	1-3/8"	7/8"	2	30℃						18960	15550	12600	10050	7880	6040	4500	2160
						50℃						13200	10690	8520	6670	5090	3750	2620
D2DB*-75X	7.5	28	1-3/8"	1-1/8"	2	30℃			33340	27970	23260	19150	15600	12540	9940	7740	5890	4340
						50℃			23610	19670	16240	13260	10680	8460	6550	4880	3430
D3DC*-75X	7.5	38	1-3/8"	1-1/8"	3	30℃								16250	13030	10260	7920	5950	2960
						50℃								11060	8670	6640	4930	3480
D3DC*-100X	10	38	1-3/8"	1-1/8"	3	30℃			45400	38110	31710	26130	21290	17140	13600	10600	8090	5980
						50℃			31110	26050	21640	17830	14530	11680	9230	7100	5230
D3DS*-100X	10	49.9	1-3/8"	1-1/8"	3	30℃								21870	17650	14030	10960	8370	4450
						50℃								15160	12130	9540	7360	5510
D3DS*-150X	15	49.9	1-5/8"	1-1/8"	3	30℃			59730	50290	42010	34780	28520	23140	18560	14680	11430	8710
						50℃			40770	34270	28620	23720	19490	15840	12690	9960	7550
D4DL*-150X	15	70.8	1-5/8"	1-1/8"	4	30℃						48040	39600	32280	25980	20610	16070	12270	6450
						50℃								21950	17410	13560	10290	7530
D4DT*-220X	22	84.7	2-1/8"	1-3/8"	4	30℃						56660	46770	38200	30830	24560	19250	14790	7990
						50℃								24950	19840	15510	11850	8740
D6DL*-270X	27	106	2-1/8"	1-3/8"	6	30℃						70030	57850	47280	38190	30430	23880	18380	10010
						50℃							38700	31280	24940	19560	15000	11110
D6DT*-300X	30	127	2-1/8"	1-3/8"	6	30℃						82740	68350	55870	45130	35970	28230	21740	11850
						50℃							46850	37920	30300	23820	18330	13660
D8DL*-370X	37	151	2-5/8"	1-5/8"	8	30℃						100600	82980	67770	54710	43580	34170	26270
						50℃								46310	36900	28910	22120
D8DT*-450X	45	181	3-1/8"	1-5/8"	8	30℃							95370	78040	63150	50470	39750	30740
						50℃								52770	42240	33300	25700
R134a MED/HIGH TEMPERATURE

D2DL*-40X	4	23.7	1-3/8"	7/8"	2	30℃	20010	16440	13350	10690	8420	6500	4880
						50℃	14980	12210	9820	7770	6020	4530	3260
D2DB*-50X	5	28	1-3/8"	7/8"	2	30℃	24580	20230	16460	13230	10480	8140	6170
						50℃	18780	15350	12390	9850	7690	5840	4260
D3DA*-50X	5	32.2	1-3/8"	7/8"	3	30℃	27110	22370	18270	14740	11730	9170	7030
						50℃	21020	17210	13920	11100	8700	6650	4900
D3DC*-75X	7.5	38	1-3/8"	1-1/8"	3	30℃	32760	27070	22140	17910	14290	11230	8650
						50℃	25200	20710	16830	13510	10680	8270	6200
D3DS*-100X	10	49.9	1-3/8"	1-1/8"	3	30℃	42250	34940	28610	23150	18500	14560	11240
						50℃	32960	27140	22130	17830	14170	11050	8370
D4DA*-100X	10	56	1-5/8"	1-1/8"	4	30℃	49350	40990	33730	27480	22140	17620	13810
						50℃	37000	30520	24940	20160	16080	12610	9630
D4DH*-150X	15	70.8	1-5/8"	1-1/8"	4	30℃	60590	50060	40930	33070	26350	20670	15880
						50℃	45810	37500	30340	24210	18980	14520	10690
